Product Details:
Payment & Shipping Terms:
|
| Name: | Double Shaft Shredder | Application: | Recycle Waste Plastic |
|---|---|---|---|
| Shaft Design: | Double Shaft | Blades Material: | Special Alloy Steel |
| Processed Material: | Plastic Flexible Film ,hollow Drum,containers,bottles | Main Motor: | 15KW*2 |
| Key Words: | Double Shaft Shredder,Plastic Shredder Machine | Core Components: | Motor, Gear, Engine |
| High Light: | DS600 double shaft shredder machine,15KW double shaft shredder machine,15KW plastic shredding machine |
||
Heavy Duty Plastic Film Woven Jumbo Bag,Fish Net Double Shaft Shredder
Brief info:
| Type: | Powerful Heavy Duty Double Shaft Shredder Machine |
| Model No.: | DS600.DS800,DS1000,DS1200,DS1500 |
| Application raw material: | PP PE(HD,LD,LLD) PS ABS PVC PA PS ect. |
| Raw material shape: | Drum,containers,bottles,barrels,film,fish net,woven bag,fabric ,wood,pallets ,carboard, metal ect |
| Core Components | the motor, Reducer, rotating knife shaft, imported knife, fixed knife rack, base cabinet, hydraulic cylinders, pumps, cylinders, ect |
| Structure: | Top Feed |
| Knife Classification: | Claw Knife shredder |
| Knife Roller: | Solid Knife Roller |
| Certification: | CE |
| Export Markets: | Global |
| Packing: | Export Standard Package |
| Origin factory location: | Zhangjigang City, Jiangsu Province, China. |
| HS Code: | 84778000 |
Description:
DS series Double shaft shredders is a kind of heavy duty shear type size reduction machine. They adopt to PLC automatic control for start,stop, reversion and overload reversion. It’s specially designed for bulky and tough materials such as varies size containers,bottles, barrels,waste packaged wastes,plastic trays,TV /refrigerator shells, tyres, so as some woods, metals and medical wastes.
Main technical parameter of Double Shaft shredder:
| Model |
Power(KW) |
Blades thickness(mm) |
Rotary diameter(mm) |
Capacity approx.(kg/h) |
| DS600 | 22×2 | 25mm~100mm | ф300mm | 500-800 |
| DS800 | 30×2 | 25mm~100mm | Ф460mm | 1000-1200 |
| DS1000 | 37×2 | 25mm~100mm | Ф460mm | 1200-2000 |
| DS1200 | 45×2 | 25mm~100mm | Ф520mm | 1800-2500 |
| DS1400 | 55×2 | 25mm~100mm | Ф520mm | 2000-3000 |
| DS2000 | 75×2 | 25mm~100mm | Ф520mm | 2500-4000 |
Features:
1.Low rotatio rate,Low noise, High torque cutting with High output
2.High quality gearbox equipped for driving system
3.High thickness steel used on sturcture and frame for enhancing the stability of equipment.
4.Shear blades material adopt to Special alloy steel, SKD11(D2).
5.Easy for operation and maintainence
6.PLC program control system, automatically rotating, stop and realize fully automatic operation of equipment, safe and reliable running of the machine
7.Electrical overloading protective
More Photos:
