Product Details:
Payment & Shipping Terms:
|
| Color: | Red | Material: | D2 |
|---|---|---|---|
| Capacity: | 300-3000kg/h | Voltage: | 380V/50Hz/3Phase |
| Condition: | New | Weight: | 700-3000kg |
| Power: | 30-90kw | Plastic Type: | PP/PE,PET,PP,ABS,PVC |
| High Light: | D2 Plastic Shredder Machine,3000kg Plastic Shredder Machine,3000kg single shaft shredder |
||
Features:
The shredder rotation speed of main rotor ranges from 60~100rpm unlike the granulators with spin in high speed. They could working gentle even when process really rough pieces.
Long life knives used. The unique designed square knives are bolted on the strong rotor and the jagged teeth knife installed in front side of the cut chamber stationary knife which are the key parts for cut off all the feeded materials.Square knives has four edges could be change before replacement.
High quality gearbox used on driving system.
High thickness steel used on sturcture and frame for enhancing the stability of equipment.
The PLC controlled hydraulic pusher forces material to the rotor automatically.
The screen filter sizes ranges for varies material particle size control.
Easy for operation maintainence
Single shaft shredder models&specification:
| Model |
Power (KW) |
Hydraulic power (KW) |
Rotor diameter (mm) |
Capacity approx. (kg/h) |
| SS600 | 18.5/22 | 1.5 | 300 | 300-500 |
| SS800 | 37/45 | 2.2 | 400 | 500-800 |
| SS1000 | 55/75 | 2.2 | 400 | 800-1000 |
| SS1200 | 75/90 | 5.5 | 450 | 1000-1500 |
| SS1500 | 90/110 | 5.5 | 500 | 1500-2000 |
