Product Details:
Payment & Shipping Terms:
|
| Warranty: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
|---|---|---|---|
| Condition: | New | Weight: | 5-15tons |
| Certification: | CE | Material: | LDPE |
| Final Product: | Clean Flakes | Final Flake Size: | 100mm |
| Water Consumption: | 5-8 Tons | Color: | Red And Black |
| Application: | Washing | Voltage: | Customized |
| High Light: | LDPE Waste Plastic Recycling Lines,100mm Plastic Recycling Lines,100mm waste plastic recycling machine |
||
LDPE Waste Film Washing Machine In Plastic Recycling Lines
This unit is mainly for PP PE plastic film: the used plastic film are teared and crushed, then after being washed, dewatered and dryed, the water content will be very low, and PP/PE film after being washed can be directly granulated (water-ring palletizing), the gained granules are even and smooth with shiny surface. So, it is an ideal equipment in waste plastic recycling industry, with leading technology in the world.
We professionally manufacture plastic machinery and waste plastic washing production lines, PP/PE waste plastic film washing production lines, pipes and shape pipes production lines, and various auxiliary machines. Our products are more reasonable in design, more excellent in processing and more durable in usage.
Details:
| S/N | Item | Requirement | |
| 1 | Capacity: | 1000kg/hr | |
| 2 | Raw material: | Post-consumer LDPE film | |
| 3 | Final Products: | Recycled Clean flakes with below parameters: | |
| Flakes size | 100 mm | ||
| Moisture Content | 1~3% | ||
| Total impurity | 200ppm | ||
| 4 |
Working condition:
|
Warehouse/workshop: Straight line dimension: 32x3.5x4.5m (also we can install the line as “U” or“L” shape) Plant height: >5m Area: >500 ㎡ |
|
|
Power supply:Supply voltage: 3*380V+N+PE; Voltage tolerance: +5%/-5%; Control voltage: 24VDC+220VAC; Frequency: 50HZ+-2% |
|||
|
Wire/cables:from power supply to control cabinet of this production line and all electrical cables from control cabinet to every single machine. Air source: 0.6-0.8MPa All water supplying and draining piping Water supplying and water drain pools underground Water treatment system can buy optional Steam supplying can buy optional to instead of electricity heating Other installation facility and tools Sound proof for the crusher and other machines optional choose |
|||
|
5 |
Energy consumption: |
Installed Power about:120KW Actual consumption 120*70%=84KW Consumption: 10 tons/h(Proposed water-treatment project) Pressure: 0.4Mpa,The water consumption is 200kg/h, and the water circulation is 9.8 tons per hour.Steam supply Labor requests:2-3 persons. |
|
Machine parts list:
| NO | Machine name | Quantity | Remark | |
| 1 | Belt Conveyor | 1sets | Necessary | |
| 2 | Friction washer | 1set | Necessary | |
| 3 | Wet Crusher | 1set | Material of blades: SKD-11 | |
| 4 | Lower Speed Friction Washer | 1set | Necessary | |
| 4 | Floating Washer | 2set | Necessary | |
| 6 | Screw Conveyor | 2set | Necessary | |
| 7 | blower system | 1set | Necessary |
